Current transformer split transformer core

application Details

Introduction

Transformers are used to provide the power required by electrical equipment. It has many parts. The iron core and windings are the main components of the transformer. There are many types of iron core transformer foundations, such as iron core, air core, ring core, cylindrical core, etc.

An iron core transformer is an electrical device with an iron core made of iron. The flux-carrying capacity of iron is greater than that of other components. This ability is called permeability. When the primary winding is connected to AC power, it generates a magnetic flux in the core. The iron core stimulates the secondary winding very well.

technical parameter

Technical Data

Model	DKSC-1200-500/10
Low-voltage connection	Y pattern
Product drawing number	5SY.641.1200-500.10.2
Total stack thickness	Two hundred and sixteen millimeters
Low-voltage turns	Seventeen turns
Total weight of iron core	One thond, four hundred and seventy-three kilos
Low Voltage	Four hundred volts
No-load loss	Less than one thond, seven hundred watts

The iron core is mainly composed of the iron core body, fasteners and insulation:

(1) The iron core body, magnetic conductor, is made of electrical steel sheet.

(2) Fasteners, clamps, screws, glass banding belts, rigid lashing belts and cushions, etc.

(3) Insulation, clamp insulation, insulating pipe and insulating pad, grounding lug and pad, etc.
