The transformer core is composed of silicon steel sheets, in order to reduce the heat loss in the core, the core is stacked from silicon steel sheets with a thickness of 0.23-0.5mm.
Thickness:
0 - 155 mm
Technique:
Cold Rolled
Product Details
Parameter
Advantage
Service
Message
application Details
Introduction
The silicon steel sheet used for transformers has a relatively high silicon content. Both sides of the silicon steel sheet are coated with insulating paint, so that the silicon steel sheets stacked on top of each other are insulated from each other, and the thickness of the insulating paint is only a few microns.
The part of the winding sleeve in the iron core is called the "core column", and the part that only plays the role of the magnetic circuit without the winding is called the "yoke". Where the iron core surrounds the winding, it is called shell type; Where the windings surround the core column, it is called the core type.

technical parameter
Technical Data
Model DKSC-500/20
Low-voltage connection Y pattern
Product drawing number 5SY.641.500.20.3
Total stack thickness One hundred and fifty-five millimeters
Low-voltage turns Thirty turns
Total weight of iron core One Thond and seventy-eight kilos
Low Voltage Four hundred volts
No-load loss Less than one thond, one hundred and ninety-five Watts


Product features
1.No load voltage regulating transformer need to adjust the tap of high-voltage side only when the power is cut off,
so as to change the ratio of the transformer to regulate the voltage at the low-voltage side.Its regulation range is small, generally within ± 5%, It can only be adjusted once or twice a year.Most transformers in power system are no-load tap transformers.

2.The on load tap changing transformer has a special switch, which can change the tap position without power off (with load).Its voltage regulation range is large, generally more than 15% or even up to 30%, and it can be adjusted  automatically for several times a day.

3.No excitation voltage regulation refers to no-load voltage regulation,which can be adjusted only when the transformer is off.On load tap chaning transformer can change the voltage by changing the tap position when it is on running.

4.OLTC switch has the advantages of frequent on-off, no spark and long service life.The traditional trigger circuit of power electronic switch has the problem of electrical isolation.The application of optical fiber communication technology to the medium and high voltage trigger control system can effectively solve the problem of high and low voltage electrical isolation.
